MINGLEI
Looking to upgrade your home with high-quality windows that are not only energy-efficient but also aesthetically pleasing? Look no further than the MINGLEI Energy Star Aluminium windows with Customized Triangle and Trapezoid Shape Beautiful Triple Glazed Picture Window.
Made from top-of-the-line aluminium material, these windows are not only durable and long-lasting but also energy-efficient, helping you save on your energy bills in the long run. The Energy Star rating ensures that these windows meet strict energy efficiency guidelines, making them a smart choice for any homeowner looking to reduce their carbon footprint.
But it's not just about energy efficiency - these MINGLEI windows have also been designed with style and beauty in mind. The customized triangle and trapezoid shapes add a unique touch to your home, creating a modern and sophisticated look that is sure to impress guests and neighbors alike. The triple glazed picture window allows for maximum natural light to enter your home, brightening up any room and creating a warm and welcoming atmosphere.
In addition to their energy efficiency and beauty, these windows are also customizable to fit your specific needs and preferences. Whether you're looking for a specific size, color, or design, MINGLEI can work with you to create the perfect window solution for your home.
So why settle for ordinary windows when you can have the best of both worlds with MINGLEI Energy Star Aluminium windows with Customized Triangle and Trapezoid Shape Beautiful Triple Glazed Picture Window? Upgrade your home today and enjoy the benefits of energy efficiency, style, and customization all in one package. Make the smart choice for your home - choose MINGLEI windows.
1. Profile |
6063-T5 Thermal break aluminum alloy |
||||
2. Profile brand |
Germany Schuco system, Domestic system |
||||
3. Surface finish |
Powder coating, Anodized, Woodgrain transfer, Elestrophoresis, Fluorocarbon paint. |
||||
4. Profile thickness |
1.6 mm-3.0mm |
||||
5. Glass option |
Double insulated glass: 5mm/6mm+12A/15A+6mm, warm edge spacer low-e & argon gas optional
Triple insulated glass: 5mm+ 9A/12A/15A/18A+5mm+ 9A/12A/15A/18A+5mm, warm edge spacer low-e & argon gas optional
Laminated insulated glass: 5mm+ 0.76PVB/ 1.14PVB+5mm+12A+5mm, clear, tinted, reflective, tempered optional |
||||
7. Hardware |
Germany imported Schuco brand, Siegenia, G-U, Hoppe, Italy Giesse, Sonbinco |
||||
8. Seal & strip |
Germany Orginally imported EPDM Rubber sealing strip, black or grey color |
||||
9. Screen optional |
Nylon/fiberglass mesh material, Stainless steel mesh screen etc |
||||
Product performance |
ML101 Series |
ML 85 series |
ML 76S series |
European U-Value (Metric/SI) |
0.79 W/(m²K) |
1.19 W/(m²K) |
1.19 W/(m²K) |
American U factor (U. S. /I-P) |
0.14 |
0.21 |
0.21 |
Rw (dB) |
38 |
35 |
35 |
Wind load resistance (Pa) |
≥ 2400 Pa |
≥ 2400 Pa |
≥ 2880 Pa |
Water tightness (Pa) |
≥ 580 Pa |
≥ 580 Pa |
≥ 440 Pa |
Canadian Air infiltration/exfiltration |
A3 level, Metric ≤0.07 L/sm2 Imperial ≤ 0.014 cfm/ft2 |
A3 level, Metric ≤0.07 L/sm²
Imperial ≤ 0.014 cfm/ft²
|
A3 level, Metric ≤0.19 L/sm² Imperial ≤ 0.038 cfm/ft² |
What Makes Minglei Products One Of The Best Choices For Buildings? |
||||||||
It’s an honor for us that you choose our products., We are the top of the "Alibaba " merchant in the window and door industry on this platform, which objectively shows that our product quality and factories strength is recognized by Alibaba, we are also the most professional company exporting windows and doors from China to the United States. Our expertise will also ensure that the products you buy, from price to quality to after-sales, are the first in terms of overall cost effectiveness. Our expertise is reflected in: |
||||||||
1 / PROVIDE THE PROFESSIONAL DOOR-TO-DOOR SERVICES |
Considering that it may be your first time to purchase valuable items in China, our specialized transportation team can take care of everything include customs clearance, documentation, importation, and extra door-to-door services for you, you can just sit at home and wait for your goods to come to your door. |
2 / GUARANTEE THE DURABILITY OF PRODUCTS UP TO 25 YEARS WARRANTY |
||
The first and only promises |
||
In our opinion, quality means never having to compromise. The high-quality aluminum and components that we use allow us without compromising structural strength. In other words, even with slim frames, we offer a high performing product for you. Our research and development team made sure that you still get unrivaled thermal insulation, high performance, and top-quality hardware on the 10 YEARS WARRANTY. The TPS glazing ensures that no air leakage and fogging issues on products for 25 YEARS WARRANTY. |
||
3 / PROVIDE FREE DESIGN ASSISTANCE TO OPTIMIZE YOUR PLAN & BUDGET |
We are very happy and look forward to a long-term partnership with you, as with our other partners in US, where our service and strength in window and door expertise can help our partners save more time and money. Minglei has been working for the North American market for a decade, we provided the most professional plan and meaningful design with ideal price to meet all our client’s highly customized demands. With our own expertise we provide no-cost design development & contract documentation with CAD & BIM drawings, including elevation & details & installation design. Helping clients to accurately control budgets by analyzing the overall plan, including to provide the schematic design to help determine products within cost parameters. Such as use lower cost products in inconspicuous locations to reduce the overall budget: If the direction is not under long time sunlight, do not use Low-E glass; use PVC windows or aluminum windows instead of solid wood windows in unimportant rooms such as toilets or storage rooms. |
4/ SAVE YOUR MONEY ON INSTALLATION COSTS |
We have several international patents to reduce clients’ labor costs, such as our unique flanges and assembly type tubular design, which is different from the other products on the market. What sets us apart among Chinese counterpart is that all our products are equipped with nail fin structures for quick and easy installation. Labor costs during installation may exceed of the window and door price, therefore, our exclusive patent allows users to not only get a significant increase in installation efficiency, but also greatly reduce the labor cost of window and door installation. A cost that may bring you unexpected savings that farexceed the price difference you may care about now. |
5 / GUARANTEE 0 DAMAGE PACKAGING, DETAILED INSTRUCTIONS FOR EASY INSTALLATION |
We export tens of millions of dollars of windows and doors to the U. S. every year, and we know that improper packaging can cause breakage of the product when it arrives on site, and the biggest loss from this is, I'm afraid, the cost of time, after all, workers on site have requirements of working time and it need to wait for a new shipment to arrive in case of damage occurs to the goods. So, we pack each window individually and in four layers, and finally into (non-fumigated) wooden boxes, （window with nailing fin packed with added four wooden corner guards for higher safety and stability）and at the same time there will be a lot of shockproof measures in the container, to protect your products. We are very experienced on how to pack and protect our products to ensure them to arrive at the sites in good condition after the long-distance transportation. What the client concerns, we concern most. |
6 / SAVE YOUR TIME ON DELIVERY |
During the epidemic, it is very difficult to book shipping containers for export (not simply the increasing fees, many exporters cannot book containers on time) which will not only directly affect the normal schedule of your project, but also will cause you a greater increase in costs that were not expected. We are the top of the "Alibaba " merchant in the window and door industry on this platform, we have priority booking rights and get the best price for the shipping, so we can guarantee that your goods will arrive as scheduled and will save you a lot of money. |
7 / HELP YOU ON INSPECTOR’S VERIFICATION |
We have a lot of projects in the USA and Canada, and we are well known for the local building code requirements. Due to the climatic characteristics of each city, there are very clear requirements for the insulation performance of windows, so we have a lot of certificates. |
8 / WITH HIGH PRODUCTIVITY FACTORIES, WE SAVE YOUR TIME ON DELIVERY |
Our products are manufactured in China, large state of the factories, sufficient to supply the largest projects, whilst remaining competitive Over 100, 000㎡ factory area with 500, 000㎡ /year production capacity, so that means we can make the fastest possible production and fastest delivery of our products to meet clients’ time demands. Hangzhou Minglei Industry Co., Ltd. is a professional supplier which engaged in the research, development, sale and service of energy efficient aluminum windows and doors, vinyl & upvc windows and doors, curtain wall, louver etc. We are dedicated to energy efficient, eco-friendly, and cost effective system windows and doors, and through our research & development, having made great achievements in the performance category such as thermal insulation, structural strength, weather proofing, sound insulation, and condensation resistance.
|
